Guangzhou Guangxin Communication Equipment Co., Ltd.
| Payment Terms | Western Union, L/C, T/T |
| Supply Ability | 300ton/month |
| Delivery Time | 20-30days |
| Packaging Details | Cotton sheets or cloth package by bundle |
| Product Name | 30m Tubular Lattice Tower with Cable Tray / Climb Ladder |
| Steel Structure | HDG Lattice Steel Tower |
| Material | Steel Q355B(GB/T 1591) |
| Hot-dip Galvanization | ISO 1461 2009, ASTM A123 |
| Tension strength (Mpa) | 360~510 |
| Tower Type | Self Supporting Angular / Tubular |
| Connection Type | Parts for connection or installation will be provided |
| Design Wind Speed | 35/210kph |
| Design of pole | Against earthquake of 8 grade |
| Warranty | 10 years |
| Tower Lifespan | 50 years |
| Brand Name | Guangxin |
| Model Number | GX-5656G |
| Certification | ISO9001 |
| Place of Origin | Guangzhou |
View Detail Information
Explore similar products
Q235b Q345b Telecommunication Mobile Cell Tower For Antenna Radio And TV
Hot Dip Galvanized Steel Structure Tower Radio Antennas Angle Plates
3 Legged Angular Steel Communication Tower Connecting Flat Plates
4 Legged Steel Lattice Tower Powder Coating Anti Corrosion Treatment
Product Specification
| Payment Terms | Western Union, L/C, T/T | Supply Ability | 300ton/month |
| Delivery Time | 20-30days | Packaging Details | Cotton sheets or cloth package by bundle |
| Product Name | 30m Tubular Lattice Tower with Cable Tray / Climb Ladder | Steel Structure | HDG Lattice Steel Tower |
| Material | Steel Q355B(GB/T 1591) | Hot-dip Galvanization | ISO 1461 2009, ASTM A123 |
| Tension strength (Mpa) | 360~510 | Tower Type | Self Supporting Angular / Tubular |
| Connection Type | Parts for connection or installation will be provided | Design Wind Speed | 35/210kph |
| Design of pole | Against earthquake of 8 grade | Warranty | 10 years |
| Tower Lifespan | 50 years | Brand Name | Guangxin |
| Model Number | GX-5656G | Certification | ISO9001 |
| Place of Origin | Guangzhou | ||
| High Light | Tubular Lattice Communication Tower ，30m Communication Tower ，Telecom Steel Tower With Climb Ladder | ||
30m Tubular Lattice Communication Tower with Cable Tray / Climb Ladder
Communication tower technical indicators:
a) Communication steel Lattice tower height: refers to the vertical distance from the base of the tower foot to the installation location of the lightning rod;
b) Wind pressure requirement: Determine the wind pressure according to W0=V02/1600 by taking the average maximum wind speed V0 (m/s) of the 10-year once-in-tact 10-minute period of the local comparatively empty ground and flat surface with a height of 10m. kN/m2;
c) Full-load wind load: Calculate based on the number of antenna layers and the number of microwave antennas per layer, and the antenna diameter in a specific project;
d) Communication tower flexion angle: less than 1 degree;
e) Center tilt: The verticality of the tower shall not be greater than 1/1500 of the height of the steel Lattice tower ;
f) Seismic strength: ≥8°;
g) The period of preservation: not less than 30 years in the local environment;
h) Galvanizing requirements: General thickness greater than 86 microns, uniform thickness, smooth surface. The specific situation is determined according to the specific project;
i) Material: Q345 Q235
j) Source of steel: Baosteel / Shougang / Handan Iron and Steel
Specification of lattice tower:
| Material | Tubular Steel, Angle steel plates, Flat steel plate |
| Steel Type | Weldable low carbon structural steel |
| Steel Grade | GB Q235, Q345, BS 4360, ASTM A36 etc. |
| Yield Strength | Fy≥235MPa |
| Tensile Strength | Fu≥400MPa |
| Elongation | σ≥20% |
| Surface Finish | Hot dip galvanization |
| Galvanized layer | T≥65μm |
| Height | 20m to 100m, customized to requests |
| Design | 4 legs self-supporting or free standing lattice tower |
| Structure | 1 to 5 platforms, each platform comes with 4 to 6 brackets for mounting antennas or specified number of brackets for mounting antennas, microwaves, RRUs and other devices. |
| Supply mode | CKD(Complete Knocked Down), SKD(Semi-Knocked Down), DKD(Direct Knocked Down) |
| Fixing/Fastening | Bolts and nuts, connecting plates |
| Configuration | Foundations/anchoring bolts, tower sections, 1-5 platforms (optional), mounting brackets, ladder, anti-fall safety system, lightning rod, earthing plate etc. |
| Wind Load | 0.35-1.0kN/sqm |
| Lifespan | 20-50 years |
| Warranty | 5 years |
| Applications | GSM/3G/4G/5G/FM radio antennas, microwaves, telecom stations. |
Communication tower product classification:
a) Classification by material: angle steel towers, steel pipe towers.
b) Classification by structure: four-posted angle steel towers, three-column steel tube towers, single-tube towers (single tube towers), and pull-line towers.
c) According to the support methods: self-standing towers, pull-line towers;
d) According to location: ground tower, roof tower;
e) The types of communication towers of our company: general communication towers, beautification communication towers, bionic tree communication towers, and landscape communication towers.
